Accoseal系列软木橡胶-可靠且应用广泛的密封材料

Accoseal 是一系列市场知名且广泛指定的基于软垫圈技术的密封材料,在汽车密封环境中具有悠久的历史,同时提供具有成本效益的最终产品定制和制造选项。

软木和精选橡胶的独特混合物产生了用于软垫圈密封的材料,由于减少了侧流,允许更大的接触面积和更高的压缩比,从而保证有效的密封屏障,防止潜在的法兰表面缺陷、扭曲和泄漏路径。

材料一致性

在冲压钢或轻质组件中,Accoseal 软木橡胶材料特别有用,能够以较小的紧固件负载和最小的硬件变形进行压缩,从而实现整体优化的系统设计。与其不可压缩的对应物(如橡胶)相反,它的受控侧流允许凹槽组装而无需余量(无挤出现象)。

耐化学性

Accoseal® 产品具有针对汽车应用介质(如燃料、润滑剂和冷却剂)的广泛特性。专用等级是 UL 列出的,如 NC710、NC711 和 NC711G,属于 UL157 燃料类别。尤其是我们的环氧氯丙烷级 NC711G 已经在生物柴油和生物乙醇燃料混合物中进行了广泛的测试,成绩显著。

Accoseal 材料型号及性能参数如下:

Product Format Compressibility (%)
400psi / 28 Kg/cm2
Characteristics and Uses Certifications
DC100 Sheets / Rolls 25 - 45 General-purpose gasket and sealing material; high cork content, minimum side flow.
DC179 Sheets  35-50 Highly compressible material for low bolting pressures
DC205 Sheets / Rolls 15 -30 / 25-45 Economical, highly compressible material for low bolting pressures.
LC800 Sheets 10 -30 Outstanding flexibility and resilience over wide range of temperatures. Excellent for coolant use.
NC709 Sheets 30 - 50 Soft, highly compressible for low bolting pressures; oil and solvent resistance.
NC710 Sheets / Rolls 75 / 70 Medium compressibility, with maximum oil and solvent resistance UL listed
NC711 Sheets / Rolls 10 - 25 / 15 - 30 Low compressibility, with maximum resistance to oils and solvents UL listed
NC733 Sheets 10 - 30 Performs in a wide range of wet or dry friction applications, operating successfully on jobs ranging from printer drives to heavy-duty transmissions in tractors and road graders.
NL76 Sheets 30 - 45 @7kg/cm2 Highly compressible, resists fatigue; for cushion pads,low sealing stress requirements.
NC711G Rolls  15 - 30 High quality, low compressibility with excellent chemical resistance to all fuel types UL listed  UL listed
